TSD FSTN Grey 256x128 dots Graphic Lcd Module



  • Model Name: TSM256128C-F
  • LCD Type: 256*128 dots lcd
  • Resolution: 256*128
  • Viewing angle: 6H
  • Driver IC: RB0086
  • Voltage:5V
  • Operating Temperature: -20 ~ +70℃
  • Storage Temperature: -30 ~ +80℃

Description:

The TSM256128C-F is a 256*128 dots dot-matrix LCD module. It has a FSTN panel composed of 256 segments and 128 commons. The LCM can be easily accessed by microcontroller via 6800 series interface. We have STN-YG,STN-blue, FSTN, Positive/negative, Transflective/transmissive.Can customize the parameters according to your requirements such as polarizer type. lcd mode. connection way. operating Voltage.etc.

Item Spec.
Display Character 256x 128
Display type FSTN
Description 256x128 graphic lcd module
Model name TSM256128C-F
Outline Size 147x116x14.6mm
View Area 127x70mm
Active Area 120x60.12mm
Viewing angle 6 o'clock
MOQ 500pcs
Number of pins 16 pins
Voltage 3.3V
IC RB0086
Operating temperature -20-70℃
Storage temperature -30-80℃
Backlight LED



Drawing:

Interface Description:

PIN SYMBOL
1 VDD
2 VSS
3 VEE
4 CL1
5 DF
6 DISP
7 NL
8 IO68
9 CL2
10 NC
11 D0
12 D1
13 D2
14 D3
15 LEDA
16 LEDK



Applications:

For our TSM256128C-F dots Graphic lcd , it's widely using in industrial product, Industrial equipment and Industrial controllers, mechanical displays.etc.

Product Features:

1. 256128 dots lcd with 16pins

2. 5v working Voltage

3.RB0086 IC chip

4.font table support English/European/Japanses/Russian

5. TSD have full ranges of mono lcd including COB COG OLED.E-ink display. customized design are warmly welcome.





Get A Quote
If you are interested in our products and want to know more details,please leave a message here,we will reply you as soon as we can.
