Specification |
||
| LCD type | 3 inch IPS round tft display module | |
| Display type | 3" round TFT | |
| Model name |
TST030GGU-01C |
|
| Outline Dimension(mm) |
|
|
| A.A.(mm) |
74.3904x74.3904 |
|
|
Touch screen |
Available to custom |
|
| Resolution(dots)_ | 432*RGB*432 | |
| Viewing Direction | All | |
| Operating temperature(°C) | -20-70 | |
| Storage temperature(°C) | -30-80 | |
| Number of Pixel(pixels) | 432(H)x 3RGB x 432(V) | |
| Operating Volatge | 3.3v | |
| Logic Voltage | 1.8v-2.8v | |
| Pixel arrangement | RGB Vertical Stripe | |
| Display mode | Normally Black | |
| Surface treatment | Antiglare, Hard-Coating(3H) | |
| IC Package Type |
COG |
|
| Luminance | 800 nits | |
| Backlight |
white LEDs |
|
|
Interface |
RGB |
|
| Module lifetime(Hours) | 50,000-100,000 | |
