2.1 inch IPS TFT (480x480)

 /IPS 2.1 inch 480x480 350 nits RGB interface Round TFT lcd display module
Categories

480x480 2.1 inch tft
480x480 2.1 inch tft 480x480 2.1 inch tft 480x480 2.1 inch tft 480x480 2.1 inch tft 480x480 2.1 inch tft 480x480 2.1 inch tft 480x480 2.1 inch tft

IPS 2.1 inch 480x480 350 nits RGB interface Round TFT lcd display module

LCD Size: 2.1''(Normal, IPS). Brightness can be designed per customer's needs

FPC Design: Customized Interface and Pins definition/Customized FPC Shape and Material

LCD Viewing Angle: Full range of IPS LCD Options Super-wide viewing angle Glare or Anti-glare Polarizer O-film solution

Backlight(BL) design: Customized Outline Dimension BL Frame Material: Meta/Plastic/Metal & Plastic integrated/Lifetime up to 30K hours high brightness up to 350 nits

Customized CTP 0.96-50 inch: Slide, Single-touch in-cell, on-cell, G+G, G+F, GGG industry or automotive CTP solutions with OCA, OCR optical bonding

  • Item No.:

    TST020WVBS-08

  • Payment:

    T/T in advance

  • Price range:

    1000 - 10000/$8.8

  • Product origin:

    Guangdong, China

  • Color:

    Standard

  • Product weight:

    38

  • Shipping port:

    Hongkong/Yantian

  • Lead Time:

    3~4 weeks
Inquiry now
  • Specifications
  • Dimention
  • Effect
Type:
TFT
Display Size:
2.1 Inch
Supplier Type:
Manufacturer
Place of Origin:
Guangdong, China
Brand Name:
TSD
Display mode:
a-Si TFT, Normally Black, Transmissive, IPS
Resolution:
480x480
Viewing Direction:

All O'CLOCK



Outline Dimension:
56.18x59.71x2.24 mm
Viewing Area:
53.28x53.28 mm
Pixel pitch(WxH):
0.111(H) x 0.111(V)
Luminance:
350 nits
Operating Temperature:
-20°C~70°C
Storage Temperature:
-30°C~80°C
Driver IC:
ST7701S
Outline Dimension:
56.18x59.71x2.24 mm
Viewing Area:
53.28x53.28 mm
Pixel pitch(WxH):
0.111(H) x 0.111(V)
Get A Quote
