15 inch lcd monitor 1024x768 resolution TN display with LVDS interface

Specification
LCD type	15 inch lcd monitor
Display type	15 inch TFT, 16.7M color, normally white
Driver element	color active matrix thin film transistor
Display mode	Normally white (TN)
Outline Dimension(mm)	326.50x253.50x11.00
Active Area.(mm)	304.128x228.096
Resolution(dots)	1024xRGBx768
Operating Voltage	3.3V
Operating temperature(°C)	-20-70
Storage temperature(°C)	-30-80
Pixel arrangement	RGB Vertical Stripe
Surface treatment	Anti-glare
Luminance(cd/m2)	450(typ.)
Contrast Ratio	700(typ.)
Application	Notebook, advertisement display, etc.
Model Number	TST150XR01
Interface	LVDS
Module lifetime(Hours)	50,000-100,000
