4.3'' 480X272 tft lcd module with AR,AG,AF coating

Feature:

4.3'' 480X272 tft lcd module with AR,AG,AF coating

*AR,AG,AF design if need

*customized cover lens for any applications

*China factory price support .




Specification
Part No. TST043015CMHX-P
Outline Dimension(mm) 105.5x67.2x4.2(Typ.)
Display Area(mm) 95.04(H)x53.856(V)
Driver IC HX8257A
Resolution(dots) WQVGA, 480*RGB*272
Description 4.3" 500 nits brightness lcd display panel
Operating temperature(°C) -20-70
Storage temperature(°C) -30-80
Number of Pixel(pixels) 480RGB(H)*272(V)
Pixel Pitch 0.198(H)*0.198(V)
Pixel arrangement RGB Vertical stripe
Display mode Normal white,262k colors, 4.3 inch tft lcd
Surface treatment Antiglare, Hard-Coating(3H), AF,AR coating
Weight(g) 50(Typ.)
Module brightness(cd/m2) 500(Typ.)
Backlight LED Side-light type,
10 pcs. white led(20MA/chip, recomendation)
Power Consumption(w) Logic system 0.09Max.
B/L system 0.924Max.



Standard CTP Spec.:


Description

INL Specification

Touch panel Size

4.3

Glass structure

G+G

Outline Dimension(OD)

123.04*84.46mm

Product Thickness

1.6mm(max)

Glass Thickness

0.7mm

Ink View Area

97.7*56.44mm

Sensor Active Area

97.7*56.44mm

Input Method

5 Fingers

Activation Force

Touch

Surface Hardness

6H

Interface

I2C

Driver IC

FT5336

CTP PINs

10pins




CTP Customization:

We can design and customize Capacitive touch panel for you with different size, shape and Logo. Welcome to contact us for details. We would like to help you develop your project.


Custom CTP Feature

1.up to 10 touch points

2. CTP Bonding : OCA bonding or 3M double side tape

3.  AG/AF/AR coating available

4. …



Custom Process:

Confirm specific requirements → pay tooling charge → Provide drawing → confirm drawing → make tooling & samples → Samples finished → Delivery via freight or sea collect



Lead time for custom LCD:

drawing making:2-5days

tooling and samples: around 3wks
