TSD 20x2 character lcd module STN Yellow or Blue type



  • Model Name: TSM2002G-0B
  • LCD Type: 20*2 dots lcd
  • Resolution: 20*2
  • Viewing angle: 6H
  • Driver IC: ST7066-0T
  • Voltage:5V
  • Operating Temperature: -20 ~ +70℃
  • Storage Temperature: -30 ~ +80℃

Description:

The TSM2002G-0-B is a 20*2 dots dot-matrix LCD module. It has a STN panel composed of 20segments and 2 commons. The LCM can be easily accessed by microcontroller via 6800 series interface. We have STN-YG,STN-blue, Positive/negative, Transflective/transmissive.Can customize the parameters according to your requirements such as polarizer type. lcd mode. connection way. operating Voltage.etc.

Specification
Item TSM2002G-0-B
Display Character 20x2 character lcd module
Display type STN-YG,STN-blue, Positive/negative, Transflective/transmissive
Plolarize mode Positive, Transflective
Display Mode 1/16 DUTY, 1/5 BIAS
Operating voltage 5.0v
Outline 116.0x37.0x11.5max
View Area 83.0x18.6mm
Active Area 75.4x11.5mm
Viewing direction 6H
Operating temperature

-20°C-70°C

Storage temperature -30°C-80°C



Drawing:



Interface Description:

PIN SYMBOL
1 VSs
2 VDD
3 vo
4 RS
5 R/W
6 E
7 DB0
8 DB1
9 DB2
10 DB3
11 DB4
12 DB5
13 DB6
14 DB7
15 A/VEE
16 K



Applications:

For our 2002 dots character lcd TSM2002G-0-B , it's widely using in industrial product, Industrial equipment and Industrial controllers, mechanical displays.etc.

Product Features:

1.2002 dots lcd with 16pins

2. 5v working Voltage

3.ST7066-0T IC chip

4.font table support English/European/Japanses/Russian

5. TSD have full ranges of mono lcd including COB COG OLED.E-ink display. customized design are warmly welcome.
