TSD 480x272 resolution 4.3 inch IPS TFT LCD Display with SSD1963 board



  • Model Name: TSM043WQHS-72
  • LCD Type: 4.3 inch IPS TFT display
  • Resolution: 480x272
  • Viewing angle: All o'clock
  • Brightness: 600 cd/m2
  • Driver IC: SSD1963
  • Interface: MCU
  • Touch Screen: without
  • Operating Temperature: -20 ~ +70℃
  • Storage Temperature: -30 ~ +80℃

Description:



TSM043WQHS-72 is a 480x272 resolution 4.3 inch IPS TFT LCD display with MCU interface, it's with SSD1963 controller board. Outline dimension of LCD is 105.5x67.2mm, active area is 95.04x53.86mm, thickness of LCM is 3.05mm. PCB size is 105.31x40mm. LCD type is 4.3 inch TFT, transmissive mode, normally black, IPS display with free viewing direction. Backlight design is 12pcs LEDs, 40mA, standard brightness is 650 cd/m2, we also have the other higher resolution model.




Drawing:




Specifications:



General Specification
Part No.  TSM043WQHS-72
Outline Dimension(mm)

105.5(W)x67.2(H)x7.65(D)

Active Area(mm) 95.04(W) x 53.83(H)
Resolution(dots) 480x (RGB) × 272
Operating temperature(°C) -20 ~ +70°C
Storage temperature(°C) -30 ~ +80°C
Number of Pixel(pixels) 480RGB(H)xRGBx272V)
Touch panel  without
Driver IC SSD1963
Pixel arrangement RGB-stripe
Display mode Normal black, IPS, 4.3 inch TFT
Surface treatment Antiglare
View direction  All o'clock
Weight(g) TBD
Power Consumption(w) Panel TBD(Typ.)
B/L system TBD(Typ.)
Interface MCU
Module lifetime(Hours) 30,000-50,000





Pins Description
Pin No.  Symbol Description
1 Ground System Ground.(OV)
2 VCC (5V) Power supply +5.5V
3 BL_EN High, Backlight ON; Low, Backlight OFF
4 RS Data/Command Selection pin
5 WR Write signal
6 RD Read signal
7~22 DB0~DB15 MCU16-bit Data Bus
23 NC Not connection
24 NC Not connection
25 CS Chip select signal
26 RESET Reset input signal
27 NC Not connection
28 NC/XR Not connection/The touch panel × right
29 NC/YD Not connection/The touch panel Y down
30 NC/XL Not connection/The touch panel X left
31 NC/YU Not connection/The touch panel Y up
32 DISP

Standby mode control.(Normally pull high)

DISP="L", enter standby mode for power saving. Timingcontroller and source driver will turn off, all outputs are Hi-Z.DISP=H", normal operation.






Applications:



TSD is offering all kinds of TFT LCD with SSD1963 control board that are ideal for different applications including:

Embedded systems, Industrial instrustment, Security equipment, Hand-held terminals, Medical devices etc.
