| Specification | |
| LCD type | transflective 3.5" tft lcd |
| Display type | 3.5" TFT, normal white |
| Touch panel | without touch panel |
| Description | transflective 3.5" tft lcd |
| Driver element | a-si TFT Active matrix |
| Outline Dimension(mm) | 85.0x53.64x2.93 |
| v.A(mm) | 74.52x56.54 |
| A.A.(mm) | 71.52x53.64 |
| Driver IC | ILI9341 |
| Resolution(dots)_ | 320*RGB*240 |
| Viewing Direction | 6H |
| Operating temperature(°C) | -20-70 |
| Storage temperature(°C) | -30-80 |
| Number of Pixel(pixels) | 240(H)x 3RGB x 2400(V) |
| Pixel arrangement | RGB Vertical Stripe |
| Display mode | Normally white |
| Surface treatment | Antiglare, Hard-Coating(3H) |
| Weight(g) | TBD |
| Backlight | 6 LEDs, White |
| Weight(g) | TBD |
| Module lifetime(Hours) | 50,000-100,000 |
