SSD2119 controller 3.5 inch 320X240 resolution lcd screen display with RTP






					Specification




					LCD type


					TFT, Transmissive




					Display type


					1.4 inch TFT LCD, 16.7M color, normal black




					Driver element


					a-si TFT Active matrix




					Outline Dimension(mm)


					45.64*42.5*2.11




					A.A.(mm)


					35.81*35.81




					Driver IC


					-




					Item


					1.4 inch OLED




					Resolution(dots)_


					454*RGB*454




					Viewing Direction


					ALL O'clock




					Operating temperature(°C)


					-20-70




					Storage temperature(°C)


					-30-80




					Number of Pixel(pixels)


					454(H)x RGB x 454(V)




					Pixel Pitch


					0.219x0.219




					Operating Volatge


					2.8v




					Pixel arrangement


					RGB Stripe




					Display mode


					Normally black




					Surface treatment


					Antiglare, Hard-Coating(3H)




					Weight(g)


					TBD




					Backlight


					-




					Touch screen


					with CTP




					Interface


					MIPI/SPI





					Module lifetime(Hours)


					50,000-100,000
